EU Standards for the Incinerator Exhaust

ACT: Directive  2000/76/EC  of  the  European  Parliament  and  of  the  Council  of  4 December 2000 on the incineration of waste.

THE EUROPEAN PARLIAMENT AND THE COUNCIL OF THE EUROPEAN UNION,
(1) The fifth Environment Action Programme: Towards sustainability – A European Community programme of policy and action in relation to the
environment and sustainable development, supplemented by Decision No 2179/98/EC on its review(5), sets as an objective that critical loads and
levels of certain pollutants such as nitrogen oxides (NOx), Sulphur dioxide (SO2), heavy metals and dioxins should not be exceeded, while in
terms of air quality the objective is that all people should be effectively protected against recognized health risks from air pollution.
(A) Objectives:
To prevent or to limit as far as practicable negative effects on the environment, in particular pollution by emissions into air, soil, surface
water and groundwater, and the resulting risks to human health, from the incineration and co-incineration of waste.

1. The chimney should have a minimum height of 10 meters above ground level
and clear the highest point of the building by not less than 3 meters for all roofs. The topography and height of adjacent buildings within 50
meters radius should be taken into account.

2. If possible the chimney should be visible to the operator from the feeding area.
3. The addition of dilution air after combustion in order to achieve the
requirement of these guidelines is unacceptable.

4. The minimum exit velocity should be 10 m/s and at least twice the surrounding wind speed (Efflux velocity = wind speed x 2) whichever
is higher to ensure no down washing of exiting gases.

Point for the measurement of emissions shall be provided.

( A )

Daily Avg. Values

Values

Unit

1

Total dust

10

mg/m3



2

Gaseous and vaporous organic substances, expressed as total organic carbon



10



mg/m3

3

Hydrogen chloride (HCl)

10

mg/m3

4

Hydrogen fluoride (HF)

1

mg/m3

5

Sulphur dioxide (SO2)

50

mg/m3





6

Nitrogen monoxide (NO) and nitrogen dioxide (NO2)expressed as nitrogen dioxide for existing incineration hour or new incineration plants





200





mg/m3( * )





7

Nitrogen monoxide (NO) and nitrogen dioxide (NO2),expressed as nitrogen dioxide for existing incineration plants with a nominal capacity of 6 tonnes per hour or less





400





mg/m3 ( * )

WWW.HICLOVER.COMWaste Incinerators Auto Roll Air Filters
Nanjing Clover Medical Technology Co.,Ltd.

Tel:  +86-25-8461 0201

Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity(Average) 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800–1000 800–1000 800–1000 800–1000 800–1000
2nd. Chamber Temperature 1000-1200 1000-1200 1000-1200 1000-1200 1000-1200
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm
